Polystyrene Particles Mixer
video

Polystyrene Particles Mixer

Model: WGJNP
The construction process supported by the Polystyrene Particles Mixer overcomes multiple drawbacks of conventional construction practices. Traditional techniques usually only allow single-layer coating work, or require construction to be split into two separate phases due to the limited interval between the initial setting and final setting of mortar, which greatly lowers overall construction efficiency.
Send Inquiry
Product Introduction

Zhejiang Wengong Intelligent Technology Co., Ltd. is one of the leading manufacturers and suppliers of polystyrene particles mixer in China. We are committed to providing high quality machinery with competitive price. If you're going to buy advanced polystyrene particles mixer made in China, welcome to get quotation from our factory.



In the early 21st century, Wengong adopted Germany's Putzmeister mortar spraying technology. Based on the conventional mortar spraying application for manhole chambers, the company co-developed the polyurea spraying method for polymer mortar connection inside manhole chambers in collaboration with Wuhan Zhongdi University.



The construction process supported by the Polystyrene Particles Mixer overcomes multiple drawbacks of conventional construction practices. Traditional techniques usually only allow single-layer coating work, or require construction to be split into two separate phases due to the limited interval between the initial setting and final setting of mortar, which greatly lowers overall construction efficiency. In contrast, the innovative spraying method enables continuous one-pass construction for both the mortar base layer and polyurea surface layer, thoroughly resolving the low-efficiency issue that has long plagued traditional construction approaches.



Featuring high efficiency, energy conservation, shorter construction cycles, lower comprehensive project costs and superior surface flatness of finished layers, this construction technique has gained wide market recognition. It has also been successfully implemented in municipal drainage pipeline renovation and repair projects across various regions in China.



5
6



Technical parameters



Raw material ratio

1:1(fixed ratio)

Maximum work pressure

30MPa

Output

2~13Kg/min

Total power

22KW

Maximum length of material pipe

120m(Optional)

Range of raw material viscosity

200~1000CPS(At operating temperature)

Heating temperature range

0℃~80℃

Drive Type

hydraulic drive

Power supply single-phase three-phase

380V50Hz/60Hz(customizable)

Atmospheric pressure source

0.6-0.8MPa 1㎥/min

Size

1040mmX740mmX770mm

Meight

178Kg

Heating power of heater

6000Wx2 Pipeline insulation and heating

Power

3500W
