Diesel Concrete Mixer Pump

Zhejiang Wengong Intelligent Technology Co., Ltd. is one of the leading manufacturers and suppliers of diesel concrete mixer pump in China. We are committed to providing high quality machinery with competitive price. If you're going to buy advanced diesel concrete mixer pump made in China, welcome to get quotation from our factory.

BSR40‑14‑61 Diesel Concrete Mixer Pump has the same working characteristics as high‑rise mortar pumps. It uses an internal combustion engine as its power source. Its hydraulic system uses three pumps and three loops. The main pump oil line and S‑valve swing oil line work separately, so the system runs very reliably.

The main pump oil line changes direction through external pilot pressure relief control on the main control valve. This stops impact during direction switching. The main pump works steadily and smoothly. The pumping hydraulic system has overflow safety protection. When system pressure becomes too high, the main pump cuts off pressure automatically for multi‑level protection.

BSR40‑14‑61 Diesel Concrete Mixer Pump supplies steady swing force and saves energy at the same time. All pipelines use conical seals or imported rectangular seals. Pipe joints seal well and do not leak oil easily.

1. Works well at construction sites without electricity

This machine is made for moving mortar to high‑rise buildings. It runs on an internal combustion engine. It does not need external electric power on site. It can work at temporary construction sites, outdoor repair jobs and high‑rise buildings that have no electricity yet. It works better than ordinary electric mortar pumps in these situations.

2. Three‑loop hydraulic system runs more stably

Most similar equipment uses shared oil lines. This pump uses three independent pumps and three separate loops. The main pump delivery line and S‑valve swing line do not interfere with each other. Pressure stays steady during long‑time heavy‑duty work, and parts last longer.

3. Improved main oil line reversing for stable running

Pumping work often causes shock when oil lines change direction. This pump uses external pilot pressure relief control on the main valve. It slows sudden pressure changes during reversing. It stops the machine and pipes from shaking, makes reversing smoother and reduces wear on hydraulic parts.

4. Multi‑level protection stops overload damage

The pumping hydraulic system has overflow protection. It also has an automatic cut‑off device for the main pump when pressure exceeds the safety limit. It offers several layers of protection. Even if the machine runs under overload for a long time, it reduces damage to important parts and cuts down equipment breakdowns.

5. Constant‑pressure swing oil line saves fuel

The swing oil line uses a constant‑pressure pump. It provides enough power to move the S‑valve smoothly, even when pumping thick mortar. The pump adjusts oil output according to real‑time working conditions. It does not keep outputting high‑pressure oil all the time, so it uses less fuel than ordinary fixed‑displacement pumps.

6. Good sealing stops pipeline oil leakage

All hydraulic pipes use conical seals or imported rectangular seals. Sealing surfaces fit closely together. The machine can run for a long time under high pressure and vibration. Pipe joints keep sealed tightly, oil leakage seldom happens, and workers do not need to repair the machine often on site.

Hot Tags: diesel concrete mixer pump, China diesel concrete mixer pump manufacturers, suppliers, factory
