Mortar Squeeze Pump

Zhejiang Wengong Intelligent Technology Co., Ltd. is one of the leading manufacturers and suppliers of mortar squeeze pump in China. We are committed to providing high quality machinery with competitive price. If you're going to buy advanced mortar squeeze pump made in China, welcome to get quotation from our factory.

Our Mortar squeeze pump brings key benefits including clear process visibility, low pulsation and highly accurate material delivery. Users can run this unit for continuous transfer of non‑abrasive media like pastes, slurries and mortars. Many businesses from building‑materials, environmental‑protection and municipal‑engineering fields rely on the pump to move slurry across different site tasks.

A high‑strength acrylic block, manufactured as one single piece, forms the transparent extrusion drum box on this unit. Operators can look straight inside to check rollers and hoses while the pump stays in service. They keep track of hose wear and leftover material in real time, without needing to shut the whole machine down. This makes planned maintenance much easier and cuts unexpected production stops. A roller and guard‑wheel assembly forms the heart of its drive system. A chain links the drive roller to the motor for accurate speed sync, and guard wheels spread compression evenly across the hose surface. No concentrated local stress will create uneven hose wear. The pump therefore runs steadily with little vibration, and service life for the hose reaches one‑and‑a‑half times the figure seen on standard pump models.

Material transport at the pump head uses a single‑chamber, double‑roller setup fitted with several guide wheels, together with highly elastic food‑grade rubber hose. Rollers squeeze the hose to move materials in a continuous flow. Internal material hold‑up volume sits at just 0.3‑0.5L, well below values for conventional pumps. Discharge‑flow uniformity error stays within ≤±2 %. Pressure pulses during material transfer are nearly removed, creating reliable running conditions for downstream gear such as spraying and filling machines. Operators can carry out stepless speed adjustment on this pump. Output flow can be fine‑tuned from 0.5‑15m³/h to suit varied site requirements, which makes the unit well‑suited for low‑flow, high‑precision slurry transfer jobs.

These products have a wide range of applications, covering concrete 3D printing, ultra-high performance and high ductility concrete production, centrifugal spraying repair of urban municipal drainage pipe linings and manholes, reinforcement and spraying repair of box culverts and highway viaduct box girder linings, theme park artificial landscape construction, fireproof surface coating for tunnels and steel structures, grouting of light steel integrated wall insulation materials, UHPC PC casting, mortar spraying finishes for building walls, spraying repair of furnace linings and molten iron ladles and intermediate ladles in the steel industry, grouting for wind and hydropower infrastructure, grouting reinforcement of roads, bridges and tunnels, fireproof and waterproof spraying, curtain grouting, slope anchoring, and post-grouting of pile foundations.
