Cement Mixer Stator
Many users fail to notice that the machining accuracy of stator and rotor profiles has a direct impact on the overall construction efficiency and material consumption of spraying machines. Once the coaxiality error of their spiral profiles goes beyond 0.02 mm, uneven gaps will form in certain zones. Mortar delivery will then experience sudden pressure fluctuations. As a direct result, spray gun output becomes unstable, and coating thickness on walls turns uneven. Extra touch‑up work by workers will offset the efficiency gains brought by mechanical spraying.
Zhejiang Wengong Intelligent Technology Co., Ltd. is one of the leading manufacturers and suppliers of cement mixer stator in China. We are committed to providing high quality machinery with competitive price. If you're going to buy advanced cement mixer stator made in China, welcome to get quotation from our factory.
Many users fail to notice that the machining accuracy of stator and rotor profiles has a direct impact on the overall construction efficiency and material consumption of spraying machines. Once the coaxiality error of their spiral profiles goes beyond 0.02 mm, uneven gaps will form in certain zones. Mortar delivery will then experience sudden pressure fluctuations. As a direct result, spray gun output becomes unstable, and coating thickness on walls turns uneven. Extra touch‑up work by workers will offset the efficiency gains brought by mechanical spraying.
Features
This custom chrome‑plated stator‑rotor set is finished in one clamping operation on a five‑axis linkage grinding machine. Spiral profile error of the Cement Mixer Stator is kept within 0.01 mm. The chrome‑plated inner bore of the stator is processed for matching via CNC honing. After meshing, volumetric efficiency stays steadily above 92 %, and the overall output pulsation rate is controlled below 3 %. Operators do not need frequent pressure adjustments during construction. Even for continuous spraying on a 100‑meter‑long wall, no obvious joint marks can be seen. A single spray pass can reach a coating thickness of up to 20 mm without material dripping. Less mortar is required for subsequent manual levelling work. Daily spraying capacity can remain stable between 800 and 1000 ㎡, delivering over 40 % higher efficiency compared with spraying machines fitted with standard spare parts.
Technical Specifications
|
Model |
Color |
Output(L/Min at 200rpm) |
Output(L/Min at 400rpm) |
Maximum grain size (mm) |
Pumping pressure (bar) |
Length/Stator (mm) |
Rotor length without pin (mm) |
|
GL40 (D6-3) |
orange |
40 |
20 |
4 |
30 |
275/89 |
320 |
